Flow Measurement
Description
- Flow ranges starting from 0 to 1000 SLPM
- LCD display and Serial Communication
- sensor and Totalizer option
- Rugged metallic body (Aluminum/SS)
- Maximum pressure of 1000 PSIG (70 Bars)
- Leak integrity 1 x 10-9 SCCS of helium
- Analog output, Totalizer, Communication
- Store multiple gas calibration
- ±0.5% and ± 1% FS accuracy with NIST traceability
- Thermal capillary tube type (model GFC, DFC) with 1%FS accuracy and ability to operate up to 1000 PSIG common mode pressure. These controllers can be used with corrosive gases as well.
- Differential pressure multi-parameter mass flow controller (DPC) series with improved (0.5RD + 0.2%FS) accuracy and ability to operate up to 120 PSIG common mode pressure. These controllers can be used only with not corrosive gases.
Description
- Robust, compact design
- Accuracy of less than +/- 0.05% typical
- Excellent speed of response time 3-4mS
- High turn-down capability, up to 100: 1.
- Standard pressure capabilities up to 5000 PSIG.
- Linearity <0.10% with linearizing electronics
- Excellent repeatability, less than +/- 0.05%.
- Extensive primary standard NIST trace calibration capability
- High shock and vibration proof
PROCESS, AND TEST & MEASUREMENT APPLICATIONS
Turbine flow meters are used in a wide variety of applications. Some examples are automotive and aerospace and test stands; subsea control systems; feedback and control systems on aero-derivative turbine generators; as well as general-purpose industrial flow measurements. A selectable range of bearings, end connections, calibrations, and electronics are available for this series making it the most versatile and capable of meeting a wide range of applications.
HIGH SHOCK LOAD APPLICATIONS
HS Series “high shock” turbine flowmeters are specifically designed to withstand pressure spikes that create hydraulic shock waves in fluids when actuators or rams are activated. This water hammer effect can dislodge the internals or sheer rotor blades off other turbine designs. The HS Series is based on providing a high level of accuracy, with added benefits of a ruggedized housing and reinforced rotor to eliminate potential damage from fluid shock.
SANITARY APPLICATIONS
Sanitary turbine flow meters provide accuracy, versatility, and economy in measuring a wide variety of dairy, food & beverage and pharmaceutical products. Durable sanitary turbine flow meter with a 316L SS smooth finish is designed to eliminate cracks and crevices where bacteria can breed.
LOW FLOW APPLICATIONS
The Omniflo® turbine flowmeters utilize a low frictional drag bearing in a tangential design, with a very low pressure drop (20mbar) allowing the measurement of very low flow rates in either liquid or gas. These high-resolution, low-flow sensing instruments are capable of measuring flow rates as low as 0.001 GPM in liquids and 0.0015 ACFM in gasses.
Description
- Line Size: 1/16 to 2”
- Very High Viscosities Range: Up to 1,000,000 cP+
- Repeatability: ±0.05% to ±0.1% of rate
- Housing, cover and bolts are 316 SS
Description
- Accuracy : <+0.5%F.S(Typical); <+0.25%F.S(by customized)
- Temperature compensation: 0c ~ 50c
- Output : 4-20mA,0-5V,0-10V,l2C,RS485…
- Electrical Connection: Fixed cable and water proof IP67(HPT700-s); Terminal Box DIN43650 IP65(HPT700-H,HPT700-G)
- Pressure Type : Differential Pressure(Gauge Type)
- Response time:<10ms
- Certificate : ExiallCT6 and CE Certificate
- Water Proof : IP65 to Ip68 Optional by model
Description
- Matching Accuracy:0.5%
- Damping time constant : Continuous Variable from 0~100s(90%)time grading optional.
- Protection class: IP65
- Communication: Optional RS232C or RS485 serial communication interface, HART communication protocol.
- Loss of power: The internal design of the instrument has a power-off clock, which can store 16 power-off records(10 years)(need to be customized)
- Explosion–proof mark: Ex d ia [ia a] q LLC T6 Gb
- Main power : AC220V 50HZ/DC24V/DC12V/3.3V battery Power supply
- Counter : Forward total , reverse total
Description
- Linearity: 0.5%
- Repeatability: 0.2%
- Accuracy: +1%
- Type: clamp-on type
- Pipe Size: 32-6000mm
- Supply voltage: AC220V or DC24V
- Powerful Recording Function, last 64days/64month/5years
Description
- Flow ranges: 0 to 1000 LPM
- Calibrated accuracy: ±1% FS
- Brass, Stainless steel, and PTFE meters
- Rigid compact construction
- Multitube configuration for mixing or separation
